Free Plan: 1912 Chafing-Dish Buffet

A compact Mission cabinet — and the first frame-and-panel door in the collection.

Free download. No signup required.

  • Full cut list and slat layout
  • Frame-and-panel door, step by step
  • Fits a 20-inch corner
Compact Mission oak buffet cabinet with single frame-and-panel door and brass hardware

The 1912 handbook calls this a chafing-dish buffet, which tells you how much has changed. A chafing dish is a pan that sits over a flame to keep food warm, and somebody built a whole cabinet to hold one.

Today it works as a kitchen cabinet, a bar cart, or a small sideboard. Twenty inches wide, thirty-six tall, four legs, two shelves, eight slats, brass hardware, and a door.

The door is what makes this plan worth building. A frame-and-panel door is the foundation of real cabinetry — once you have made one, you have made the part that shows up in every cabinet, wardrobe and sideboard you will ever want to build.

The plan covers the leg-and-rail carcase, the shelves, the slat layout, the back panel, and the door: stiles, rails, groove and floating panel.

Project at a Glance

Difficulty
Advanced (two paneled side frames, keyed shelf tenons, and a fitted frame-and-panel door)
Main materials
Quarter-sawn oak for legs, rails, shelves and top, panel stock for the door, back panel material, shelf keys, brass hinges and pull, glue, weathered-oak stain, thin shellac and wax
Build time
Several weekends, plus finish
Tools needed
Mortising tools, saws, a plane for fitting the door, drill and driver, clamps, square, sandpaper and finish supplies
Safety
Grooving and ripping — support the work fully and keep hands out of the blade path
Source
Popular Mechanics Handbooks, 1912 (public domain)

The one rule on this build:

Do not glue the panel. Glue belongs on the joints between the stiles and the rails — the frame — and nowhere else. The panel floats loose in its groove with a small gap at the edges, and it has to stay that way for the life of the piece. Wood moves across the grain with the seasons, and a panel this wide moves enough to feel with a thumbnail. Free to move, nothing happens. Glued in place, it swells, the frame refuses, and either the panel splits or a frame joint lets go — a season later, when nobody connects it to assembly day. Dry-fit the door, pencil the panel edges, and glue only where the pencil is not.

A door is also where a shop gets tested. Stiles and rails have to come out the same length within a hair, the groove has to sit the same distance from the same face on every piece, and any error shows up the moment the door is hung against a straight reference line.

Get through that once and the question changes from whether you can build cabinetry to what you build next.
